Kemer Engineering Machinery KRT8000 8 Ton Rubber Track Undercarriage System

Name: Kemer Engineering Machinery KRT8000 8 Ton Rubber Track Undercarriage System
Brand: Ningbo Kemer Engineering Machinery Co.,ltd.
SKU: KRT8000
Price: 6.00 USD
Availability: InStock

All Products

Crawler Track Undercarriage
(179)

Hydraulic Planetary Gearbox Reducer
(78)

Hydraulic Winch Machine
(79)

Hydraulic Motor Transmission
(38)

High Torque Hydraulic Motor
(14)

Concrete Pump Truck Gearbox
(2)

Electric Winch Machine
(1)

I'm Online Chat Now

Kemer Engineering Machinery KRT8000 8 Ton Rubber Track Undercarriage System

Large Image : Kemer Engineering Machinery KRT8000 8 Ton Rubber Track Undercarriage System

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	KEMER
Model Number:	KRT8000

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$6,800.00 - $7,800.00/sets
Packaging Details:	Steel pallet ,with Stretch film Winding
Supply Ability:	50 Set/Sets per Month

Contact Now

Kemer Engineering Machinery KRT8000 8 Ton Rubber Track Undercarriage System

Description

Applicable Industries:	Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Construction Works , Energy & Mining	Showroom Location:	None
Video Outgoing-inspection:	Provided	Machinery Test Report:	Not Available
Marketing Type:	Ordinary Product	Warranty:	1 Year, 1 Year
Type:	Hydraulic Rubber Track Chassis	Loading Capacity:	8 Ton
Payload:	6.2ton	Other Motor Choice:	Available
Max Gradeability:	25°	Customized Service:	Available And Free
Color:	Black Or Per To Customer	Application:	Crawler Tracked Chassis Machine
Port:	Ningbo/Shanghai

Product Description

Kemer Engineering Machinery KRT8000 8 Ton Rubber Track Undercarriage System

Length	2612mm
Loading Capacity	8000 KG
Payload	6200 KG
Distance between center	2053 mm
Pitch	72.5 mm
Track width	400 mm
Track Frame	Weld
Motor Displacement	49.2/26.3 ml/r
Max speed	1.9/3.6 km/h
Max Output Torque(each side)	8600/4600N.m
Max Gradeability	30%

Products details:

1.Customized track frame.We can customized the Track Undercarriage System according to customer's needs.

2.Maintenance:tips to help customers how to maintain the undercarriage and how to longer the service life.

3.Good spare parts

Other Model

We can customized the Rubber Track Undercarriage System according to your needs Above is just some of our models.

Lead Time:

Quantity(Sets)	1 - 1	2 - 5	>5
Est. Time(days)	20	25	To be negotiated

Our Company

Ningbo Kemer Engineering Machinery Co.,LTD

We located in Ningbo China.With many years' experience in this field,our undercarriage parts are specially selected and fabricated.

Have been exported to South Asia,Australia,Turkey,Brazil and many other countries.

Products are widely welcomed by our customers.

Customized service is available here.We usually customized the track undercarriage according to customer's needs like the length,width,track width,loading capacity,speed and so on.If you have detailed drawing we can make accordingly.

Usually machine facotry will buy undercarriages from us and connect to their machines.

Our Products

0.5 to 80 ton Track Undercarriage System is available here.0.5 ton to 10 ton Rubber Track Undercarriage System.

We make 0.5 to 80 ton track undercarriages.

KRT3000

3 ton Rubber Track Undercarriage System

KRT4000

4 ton Rubber Track Undercarriage System

KRT1500

1.5 ton Rubber Track Undercarriage System

Customers

Our Customers

Our customers come and visit our factory and we share a good time then.DIscussed about the products and their requirements.
