52 Ratio 2 Ton Recovery Hydraulic Winch with OMP80 Hydraulic Motor

Name: 52 Ratio 2 Ton Recovery Hydraulic Winch with OMP80 Hydraulic Motor
Brand: Ningbo Kemer Engineering Machinery Co.,ltd.
SKU: HCW20
Price: 150.00 USD
Availability: InStock

All Products

Crawler Track Undercarriage
(179)

Hydraulic Planetary Gearbox Reducer
(78)

Hydraulic Winch Machine
(79)

Hydraulic Motor Transmission
(38)

High Torque Hydraulic Motor
(14)

Concrete Pump Truck Gearbox
(2)

Electric Winch Machine
(1)

I'm Online Chat Now

52 Ratio 2 Ton Recovery Hydraulic Winch with OMP80 Hydraulic Motor

Large Image : 52 Ratio 2 Ton Recovery Hydraulic Winch with OMP80 Hydraulic Motor

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	Peka
Model Number:	HCW20

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$300.00 - $1,500.00/pieces
Packaging Details:	We pack the recovery winch By Pallet
Supply Ability:	600 Piece/Pieces per Month

Contact Now

52 Ratio 2 Ton Recovery Hydraulic Winch with OMP80 Hydraulic Motor

Description

Customized Support:	OEM, ODM	Power Source:	Hydraulic
Application:	BOAT	Capacity:	20KN
1st Layer Pull Force:	20KN	Rope Speed:	5 M/min
Flow:	53 L/min	Working Pressure Diff.:	14 Mpa
Diameter:	11 Mm	Capacity Of Rope:	20 M
Hydraulic Motor:	OMP80	Ratio:	52
Port:	Port Of Ningbo Or Shanghai

Product Description

HCW and HCP Hydraulic winch series are patent products of our company and consist of a variety

of distributors with shuttle valves controlling the brake and single or dual counterbalance valves,INM type

hydraulic motor,Z type brake,C type planetary gearbox,drum,frame and so on(to see hydraulic diagram).

The user only needs to provide a hydraulic power pack and directional valve.Due to the winches fitted

with diversified valve block,it not only simplified the hydraulic system,but also improved the reliability of the

winches.In addition,the winches feature a high efficiency at start-up and operation,low noise and energy

consumption,and have a compact figure abd good economic valve.Therefore,the series have been widely

applied to hoisting salvage vehicles,cross country vehicle,military heavy truck,bulldozer.It can be used to

rescue various vehicles damaged or involved in mud and also used to pull heavy objects and to save self.

HCW and HCP series hydraulic winches have been well sold in China and also have been exported to

Netherlands,the Middle-east,the south-east Asia,Korea and so on.

Our Products

52 Ratio 2 Ton Recovery Hydraulic Winch with OMP80 Hydraulic Motor 0

NP series compact Hydraulic winch GW series standard hydraulic AF high speed hydraulic winch
winch

52 Ratio 2 Ton Recovery Hydraulic Winch with OMP80 Hydraulic Motor 3

GWJ series free fall Hydraulic winch Built-in hydraulic winch recovery winch

52 Ratio 2 Ton Recovery Hydraulic Winch with OMP80 Hydraulic Motor 6

electric winch

About Us

Our Professional Worker Team

52 Ratio 2 Ton Recovery Hydraulic Winch with OMP80 Hydraulic Motor 7

Our Advantage

1.We located In the most developed areas of China.There are many factory here.Full range of upstream enterprise and downstream enterprise.We are able to make the products with good quality and competitive price.

2.With many years experience in this field,we are one of the leader enterprise of Ningbo in this field.

3.Near to the Port of Ningbo,we cost little to transport the goods to the warehouse.And many warehouse are just 2 blocks near us.

4.With many buyers all over the world,our products are welcomed by foreign friends.

52 Ratio 2 Ton Recovery Hydraulic Winch with OMP80 Hydraulic Motor 8

A good quantity of our products and spare parts.

52 Ratio 2 Ton Recovery Hydraulic Winch with OMP80 Hydraulic Motor 9

Our Service

1. One year warranty from delivery

2. Free components for replacement within warranty period

3. Professional solution provider

4. Free technical support at any time

5. Customer training is available.

6. On-site installation and commissioning is available.

Winch FAQ

Q1:What's you MOQ?

A:MOQ is 1 piece.

Q2:What should I supply to get a suitable model of hydraulic winch and quotation?

A: In order to recommend a most suitable model of hydraulic winch we should to know:

1.Line pull(t)

2.Line Speed(m/min)

3.Drum capacity/Rope Length(m)

4.Rope Diameter(if have)

5.With braker or not

6.Which kind of machine does the hydraulic used on?

7.hydraulic system pressure and pump flow(if have)

8.other special requrements

52 Ratio 2 Ton Recovery Hydraulic Winch with OMP80 Hydraulic Motor 11
